- Quick adjustment via 1/4 turn fasteners
- Standard mounting system for all SGM Standard products
The omega bracket with 1/4-turn fasteners is intended for fastening a wide range of SGM lighting fixtures to a surface. In combination with a half coupler, it is ideal for truss mounting.
Mounting can be done easily and fast - no tools required.
Please review the Quick Installation guide (available as a download in all STD and POI products) to know more about 1/4 turn camlock mounting points and bracket dimensions.
Specification
| Physical | |
|---|---|
| Color options | Black - RAL 9004 |
| White - RAL 9010 | |
| Material | Steel |
| Net dimensions L x H x W (imperial) | 5.4 x 2.3 x 1.4 inches |
| Net dimensions L x H x W (metric) | 137 x 59 x 35 mm |
| Net weight | 0.3 kg (0.7 lbs) |
| Installation | |
| Orientation | Any |
| Rigging possibilities | 13mm / 0.5in hole diameter for locking point attachment |
| Safety features | Designed to withstand 260Kg without deformation, when locked in fixture's base. |
