- Works as an IP65-rated blinder, pixel dot, par can, pendant or truss toner — one fixture, multiple roles
- Preconfigured in 4-Lite, 8-Lite or larger builds to match your setup
- Single-source RGBALW colour with CRI up to 96
- Connects into the GENIO system with tool-free rigging connectors
- Built-in NFC for quick setup and configuration
GENIO BlinderDot is the emotional driver of the GENIO system — a blinder, pixel dot, par can, pendant and truss toner in one fixture, preconfigured for fast builds and connected into the GENIO family through SGM's tool-free connectors.
GENIO BlinderDot turns audience lighting into part of the show. It works as a blinder, a pixel dot, a par can, a pendant or a truss toner, and comes preconfigured in 4-Lite, 8-Lite or larger builds, so you start with the exact configuration your design calls for.
A single-source RGBALW engine pushes up to 17,000 lumens through a 50° beam angle, with CRI up to 96 for colour that holds up on camera as well as in the room.
GENIO BlinderDot connects into the wider GENIO system through SGM's tool-free rigging and fixture connectors — the same connector system shared across GENIO Beam and GENIO PixelBar — making it possible to stack up to 17 units vertically, with a range of additional rigging, mounting and lens accessories available to extend the setup further.
Specification
| Optical Data | |
|---|---|
| Lightsource | RGBALW |
| Photometric | |
| Color quality - CRI | >90 |
| Color temperature range | 2000K - 10000K |
| Light output - all on | 17000 lm* |
| Native beam angle(s) | 50° |
| Native field angle(s) | 90° |
| Physical | |
| Color options | Black - RAL 9004 |
| IP class | IP65 |
| Material | Aluminium |
| Plastic | |
| Stainless steel | |
| Tempered Glass | |
| Net dimensions L x H x W (imperial) | 6.3 x 8.4 x 6.3 inches |
| Net dimensions L x H x W (metric) | 160 x 213 x 160 mm |
| Net weight | 3.5 kg (7.7 lbs) |
| Electrical | |
| Input voltage (nominal) | 100 - 240 VAC; 50 / 60 Hz |
| Max power consumption | 400 W |
| Programming and Control | |
| Protocol | RDM ANSI E1.20 |
| sACN | |
| Art-Net | |
| Setting and addressing | RDM ANSI E1.20 |
| NFC | |
| Connections | |
| DMX data in/out | RJ45 / RJ45 |
| Ethernet Connections | RJ45 connectors |
| Installation | |
| Maximum Units Vertical | 17 pcs |
| Mounting point | 2 quarter-turn locking points for one Omega bracket |
| Rigging possibilities | Hanging (Using the GENIO compatible connectors) |
| Safety features | Mount for safety wire |
| Thermal | |
| Cooling | Active, Forced Air, Temperature-regulated |
| Humidity (max.) | 98 % |
| Temperature range, operating | -20°C to 45°C |
| Temperature range, start-up | -20°C to 45°C |
| Temperature range, storage | -20°C to 45°C |
| Thermal protection | Automatic overtemperature protection |
| Total heat dissipation, max power | 1364.8 BTU per hour |
| Included items | |
| Included items | 2 x GENIO Rigging Connector |
| 1 x GENIO Fixture Connector, M | |
| Foam Insert | |
Download
-
DMX Charts
-
User Manual and Specifications
Certifications & classifications
Ordering information
| Product name | Item number |
|---|---|
| GENIO BlinderDot | 80300520 |
| Accessories | Item number |
|---|---|
| GENIO Rigging Connector - Set of 6 | |
| GENIO Fixture Connector, M - Set of 6 | |
| GENIO Fixture Connector, M - Set of 6 | 83063254 |
| GENIO Rigging Connector - Set of 6 | 83063252 |
