Standard

POI-30 Wash

RGBW LED Wash Light

Housing colors
Grey RAL 7037
Custom any RAL
Info shortcuts
  • Up to 1375 lumen at 4000K calibrated white
  • RGBW quad-chip LEDs with 3000K and 4000K white options
  • Wide selection of native lens options
  • Integrated wireless DMX and AirGlow options
  • Built-in 30 watt power supply
  • Made with recycled aluminium

This thermal management techonology provides Advaced Temperature Control monitored via sensors and software, keeping optimal LED junction temperatures, and ensuring maximum reliability for long-term use. The ThermalDriveTM system includes cutting-edge heat removal via passive thermal tecniques and active forced-air cooling (depending on the product), specifically designed to maintain LED efficiency while extending fixture's lifetime.

SGM's TruColorTM luminaires use an enhanced color engine that improves accuracy and consistency both for color mixing and low-end dimming, while using the same procedures to match the SGM color palette.

SGM's integrated patented Dehumidification process eliminates humidity and breaks down corrosive molecules deriving from polluted air to avoid destructive corrosion. Inbuilt dehumidifiers constantly remove trapped hydrogen from inside of the lighting fixture in a solid estate electrolytic process with no moving parts. The DryTechTM procedure is also based on a Ingress Protection rating of 65 or 66 (depending on the fixture), intended as a full protection against dust and other particles, while ensuring protection against direct water jets.

DynaMix® is the latest version of the SGM calibrated color engine. It is a new scalable drive design which brings an unprecedented level of output to all new SGM Light products by increasing the output of mixed colors and whites through a combination of firmware and hardware. LED engines with DynaMix can utilize the full power capacity of a power source when using combinations of drive channels. What does this mean? Essentially a huge boost in output. With DynaMix each SGM fixture is capable of much greater output, maximizing efficiency and budget.

Designer selectable algorithm for advanced color path control, allowing any mixed RGB value to hold a specific color point in the spectrum by modifying the color temperature data. Color filter emulation presets react to color temperature adjustments when this color path is selected. All products featuring the next-gen VersaPathTM color engine also include the standard SGM proprietary color mixing algorithm.

The POI-30 Wash is part of SGM’s POI family—built-to-last and easy-to-install fixtures designed to withstand any outdoor environment. With five fixture sizes, multiple lens options, integrated control, built-in power, and glare accessories, the POI family offers versatile, configurable solutions for projects of any scale.



Specification

Optical Data
LED expected lifetime (L70) > 150.000 hours (Projected, under manufacturer's conditions)
Lightsource RGBW3K (quad-chip)
RGBW4K (quad-chip)
Native lens options 35°
25°
10°
100°
60°
10x60°
60x10°
Photometric
CRI > 60
Efficacy 46 lm/W
Light output - all on 1375 lm @ calibrated 4000K
Light output - blue 225 lm
Light output - green 1056 lm
Light output - red 461 lm
Physical
Color options Custom color - Any RAL
Grey - RAL 7037
Corrosion class C5 (ISO 12944)
IK rating IK08
IP class IP66
Lens material Tempered glass front
Material Aluminium
Plastic
Stainless steel
Recycled aluminium
Net dimensions L x H x W 157.6 x 187.5 x 73.5 mm
Net dimensions L x H x W (inches) 6.2 x 7.4 x 2.9 inches
Net weight 1.6 kg (3.5 lbs)
Vibration Rating 3G (Optional)
Electrical
Input voltage, nominal 100 - 277 VAC; 50 / 60 Hz
Max power consumption 30 W
Programming and Control
Protocol CRMX, W-DMX™ G2, W-DMX™ G3, W-DMX™ G4, W-DMX™ G4S
USITT DMX512A
RDM ANSI E1.20
Lumenradio AirGlow™
Setting and addressing RDM ANSI E1.20
Standalone mode Quick Color
Connections
DMX data in/out 1.5 meter cable for DMX In and DMX Thru
Power Power cable 1.5m with bare ends
Thermal
Cooling Passive
Temperature range, operating -40°C to 50°C
Temperature range, operating max 50 °C
Temperature range, operating min -40 °C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -40°C to 80°C
Total heat dissipation, max power 102.4 BTU per hour

Certifications & classifications

SGM LIGHT
SGM LIGHT
SGM LIGHT
SGM LIGHT
SGM LIGHT
SGM LIGHT
SGM LIGHT
SGM LIGHT

Ordering information

Product name Item number
POI-30 Wash, RGBW3K, 60x10°, GR, CRMX 80300134
POI-30 Wash, RGBW3K, 10°, GR, AirGlow 80300135
POI-30 Wash, RGBW3K, 25°, GR, AirGlow 80300136
POI-30 Wash, RGBW3K, 35°, GR, AirGlow 80300137
POI-30 Wash, RGBW3K, 60°, GR, AirGlow 80300138
POI-30 Wash, RGBW3K, 100°, GR, AirGlow 80300139
POI-30 Wash, RGBW3K, 10x60°, GR, AirGlow 80300140
POI-30 Wash, RGBW3K, 60x10°, GR, AirGlow 80300141
POI-30 Wash, RGBW4K, 10°, GR, DMX 80300100
POI-30 Wash, RGBW4K, 25°, GR, DMX 80300101
POI-30 Wash, RGBW4K, 35°, GR, DMX 80300102
POI-30 Wash, RGBW4K, 60°, GR, DMX 80300103
POI-30 Wash, RGBW4K, 100°, GR, DMX 80300104
POI-30 Wash, RGBW4K, 10x60°, GR, DMX 80300105
POI-30 Wash, RGBW4K, 60x10°, GR, DMX 80300106
POI-30 Wash, RGBW4K, 10°, GR, CRMX 80300107
POI-30 Wash, RGBW4K, 25°, GR, CRMX 80300108
POI-30 Wash, RGBW4K, 35°, GR, CRMX 80300109
POI-30 Wash, RGBW4K, 60°, GR, CRMX 80300110
POI-30 Wash, RGBW4K, 100°, GR, CRMX 80300111
POI-30 Wash, RGBW4K, 10x60°, GR, CRMX 80300112
POI-30 Wash, RGBW4K, 60x10°, GR, CRMX 80300113
POI-30 Wash, RGBW4K, 10°, GR, AirGlow 80300114
POI-30 Wash, RGBW4K, 25°, GR, AirGlow 80300115
POI-30 Wash, RGBW4K, 35°, GR, AirGlow 80300116
POI-30 Wash, RGBW4K, 60°, GR, AirGlow 80300117
POI-30 Wash, RGBW4K, 100°, GR, AirGlow 80300118
POI-30 Wash, RGBW4K, 10x60°, GR, AirGlow 80300119
POI-30 Wash, RGBW4K, 60x10°, GR, AirGlow 80300120
POI-30 Wash, RGBW3K, 10°, GR, DMX 80300121
POI-30 Wash, RGBW3K, 25°, GR, DMX 80300122
POI-30 Wash, RGBW3K, 35°, GR, DMX 80300123
POI-30 Wash, RGBW3K, 60°, GR, DMX 80300124
POI-30 Wash, RGBW3K, 100°, GR, DMX 80300125
POI-30 Wash, RGBW3K, 10x60°, GR, DMX 80300126
POI-30 Wash, RGBW3K, 60x10°, GR, DMX 80300127
POI-30 Wash, RGBW3K, 10°, GR, CRMX 80300128
POI-30 Wash, RGBW3K, 25°, GR, CRMX 80300129
POI-30 Wash, RGBW3K, 35°, GR, CRMX 80300130
POI-30 Wash, RGBW3K, 60°, GR, CRMX 80300131
POI-30 Wash, RGBW3K, 100°, GR, CRMX 80300132
POI-30 Wash, RGBW3K, 10x60°, GR, CRMX 80300133
Accessories Item number
POI-30 Wash Half Anti-glare Shield 83063108
POI-30 Wash Full Anti-glare Shield 83063109
