PALCO-3 Wash

Compact, foldable, high output, color-changing wash light.

Housing colors

Black RAL 9004

Info shortcuts

Powerful 40W RGBL LED with ColorBoost™ technology
CRI 85+ (calibrated at 5600K CCT)
IP65-rated for outdoor use
DMX, RDM, ArtNet & sACN via 5-pin XLR and Ethernet
Integrated LumenRadio Wireless CRMX
NFC setup with proprietary iOS & Android app

This thermal management techonology provides Advaced Temperature Control monitored via sensors and software, keeping optimal LED junction temperatures, and ensuring maximum reliability for long-term use. The ThermalDriveTM system includes cutting-edge heat removal via passive thermal tecniques and active forced-air cooling (depending on the product), specifically designed to maintain LED efficiency while extending fixture's lifetime.

All luminaires featuring this technology include all the TruColorTM capabilities, plus high color rendering (CRI / TLCI / CQS 90+) when using all RGB or RGBAM LEDs to achieve high-output dynamic whites. SGM's TruColor+TM luminaires use an enhanced color engine that improves accuracy and consistency both for color mixing and low-end dimming, while using the same procedures to match the SGM color palette.

Designer selectable algorithm for advanced color path control, allowing any mixed RGB value to hold a specific color point in the spectrum by modifying the color temperature data. Color filter emulation presets react to color temperature adjustments when this color path is selected. All products featuring the next-gen VersaPathTM color engine also include the standard SGM proprietary color mixing algorithm.

Compact, foldable, and ready for any stage.

The PALCO-3 Wash delivers high-performance RGBL wash lighting in a small, foldable form factor. Ideal for smaller productions, quick setups, and tight spaces. Easy to transport, set up, and store, the PALCO-3 Wash is designed with efficiency at its core.

With Color Boost Technology, it ensures vivid, well-saturated colors and high color rendering across the full CCT range. A full range of wired and wireless options and compatibility with filters and barndoors make it a truly versatile fixture.

Specification

Optical Data
Dominant wavelength (λd) - blue	typical 452 nm*
Dominant wavelength (λd) - green	typical 527 nm*
Dominant wavelength (λd) - red	typical 625 nm*
LED expected lifetime (L70)	50,000 hours
Lightsource	18 X High Output RGBL LEDs
Optional filters	Wall Wash Filter, PALCO
	Scrim Filter, PALCO
	Narrow - 20° Green, PALCO
	Medium - 45° Red, PALCO
	Wide - 80° Blue, PALCO
	10x60° Horizontal - Orange, PALCO
	60x10° Vertical - Yellow, PALCO
Photometric
Average CQS (CTC)	89
Average RF / TM-30-15 (CTC)	84
Color temperature range	2000K - 10000K
Efficacy	38.7 lm/W
Light output - all on	15558
Light output - blue	1604 lm
Light output - green	7903 lm
Light output - red	3276 lm
Lux @ 10m	2533 lux
Lux @ 3m	28145 lux
Lux @ 5m	10132 lux
Max. CRI @ 5600K	81
Max. TLCI @ 5600K	80
Native beam angle(s)	11°
Native field angle(s)	23°
Physical
Color options	Black - RAL 9004
IK rating	IK06
IP class	IP65
Lens material	PMMA
Material	Plastic
	Stainless steel
	Tempered Glass
	Recycled aluminium
Net dimensions L x H x W (imperial)	14 x 10.6 x 7.2 inches
Net dimensions L x H x W (metric)	356 x 268 x 183 mm
Net weight	7.5 kg (16.5 lbs)
Electrical
Input voltage (nominal)	100 - 240 VAC; 50 / 60 Hz
Max inrush current 230VAC	45 A
Max power consumption	450 W
Max power thru @ 100 V	4.1 A
Max power thru @ 230 V	1.7 A
Power factor	0.978 PF (230 V)
Standby power consumption	10 W
Thermal
Cooling	Active, Forced Air, Temperature-regulated
Humidity (max.)	98 %
Temperature range, operating	-20°C to 50°C
Temperature range, start-up	-20°C to 50°C
Temperature range, storage	-20°C to 50°C
Total heat dissipation, max power	1535.4 BTU per hour
Total heat dissipation, standby	34.1 BTU per hour
Included items
Included items	2 Omega bracket with quater-turn fasteners
